在 Raspberry Pi 4 上实现实时推理（30 帧/秒！）

# This enables the extended features such as the camera.
start_x=1

# This needs to be at least 128M for the camera processing, if it's bigger you can just leave it as is.
gpu_mem=128

# You need to commment/remove the existing camera_auto_detect line since this causes issues with OpenCV/V4L2 capture.
#camera_auto_detect=1

$pipinstalltorchtorchvisiontorchaudio
$pipinstallopencv-python
$pipinstallnumpy--upgrade

$python-c"import torch; print(torch.__version__)"

importcv2
fromPILimport Image

cap = cv2.VideoCapture(0)
cap.set(cv2.CAP_PROP_FRAME_WIDTH, 224)
cap.set(cv2.CAP_PROP_FRAME_HEIGHT, 224)
cap.set(cv2.CAP_PROP_FPS, 36)

ret, image = cap.read()
# convert opencv output from BGR to RGB
image = image[:, :, [2, 1, 0]]

fromtorchvisionimport transforms

preprocess = transforms.Compose([
    # convert the frame to a CHW torch tensor for training
    transforms.ToTensor(),
    # normalize the colors to the range that mobilenet_v2/3 expect
    transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(image)
# The model can handle multiple images simultaneously so we need to add an
# empty dimension for the batch.
# [3, 224, 224] -> [1, 3, 224, 224]
input_batch = input_tensor.unsqueeze(0)

importtorch
torch.backends.quantized.engine = 'qnnpack'

fromtorchvisionimport models
net = models.quantization.mobilenet_v2(pretrained=True, quantize=True)

net = torch.jit.script(net)

importtime

importtorch
importnumpyasnp
fromtorchvisionimport models, transforms

importcv2
fromPILimport Image

torch.backends.quantized.engine = 'qnnpack'

cap = cv2.VideoCapture(0, cv2.CAP_V4L2)
cap.set(cv2.CAP_PROP_FRAME_WIDTH, 224)
cap.set(cv2.CAP_PROP_FRAME_HEIGHT, 224)
cap.set(cv2.CAP_PROP_FPS, 36)

preprocess = transforms.Compose([
    transforms.ToTensor(),
    transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])

net = models.quantization.mobilenet_v2(pretrained=True, quantize=True)
# jit model to take it from ~20fps to ~30fps
net = torch.jit.script(net)

started = time.time()
last_logged = time.time()
frame_count = 0

with torch.no_grad():
    while True:
        # read frame
        ret, image = cap.read()
        if not ret:
            raise RuntimeError("failed to read frame")

        # convert opencv output from BGR to RGB
        image = image[:, :, [2, 1, 0]]
        permuted = image

        # preprocess
        input_tensor = preprocess(image)

        # create a mini-batch as expected by the model
        input_batch = input_tensor.unsqueeze(0)

        # run model
        output = net(input_batch)
        # do something with output ...

        # log model performance
        frame_count += 1
        now = time.time()
        if now - last_logged > 1:
            print(f"{frame_count/(now-last_logged)} fps")
            last_logged = now
            frame_count = 0

top = list(enumerate(output[0].softmax(dim=0)))
top.sort(key=lambda x: x[1], reverse=True)
for idx, val in top[:10]:
    print(f"{val.item()*100:.2f}% {classes[idx]}")

torch.set_num_threads(2)
